Description
Dual insulated cable tested to 3x the required bend angle provides increased reliability and durability.
Switchable load: avoid display of ghost voltages allowing you to draw more current from the circuit under test and avoid trip residual-current devices (RCDs)
Backlit graduated scale and backlit indicators
Built in electric torch for use in dark areas.
Audio on/off for testing in quiet areas.
Improved probe docking for secure storage.
Phase rotation indicator for 3-phase systems.
Single-pole phase test offers fast identification of live conductors.
Push-on probe tips, probe tip protector and storage accessory.
Tip protector serves as an extra hand when opening UK electrical safety outlets.
Low battery indicator.
Specifications
Voltage AC/DC: 12V – 690V
Continuity: 0 – 400 kΩ
Frequency: 0 / 40 – 400 Hz
Phase rotation: 100 V – 690 V
Resistance measurement:
Response Time (LED indicator): < 0.5s
200 kΩ input impedance:
Current draw 3,5 mA @ 690 V
Current draw 1,15 mA @ 230 V
7k Ω input impedance (with load buttons pressed): Current draw 30 mA @ 230 V
Safety rating:
CAT II 690V
CAT III 600V
IP rating: IP64
Power requirement: 2 x AAA batteries
Dimensions (L x W x H): 260mm x 70mm x 38mm
Weight 0.28kg
